Track Measurement Machine

Purpose: Measures and calculates track data for maintenance and construction, including:

• Fixed point relative amount
• Track lifting and lining volumes
• Gauge, superelevation, mileage

Functionality:

• Provides data for tamping machines with ALC systems.
• Measures absolute values relative to a geodetic coordinate system.
• Ensures precision in track positioning and geometry.

Capabilities:

• Measures straight lines, curves, and turnouts.
• Records versine, leveling, superelevation, and gauge.
• Operates at a minimum speed of 2.5 km/h.

Applications:

• New line construction
• Overhaul and maintenance work
• Ensures accurate track alignment and geometry for optimal performance.
